Catalog #
SE11400H-US000BNU4
Mfr. Part #
SE11400H-US000BNU4
Manufacturer
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:

Description

Features:

  • Specifically designed to work with power optimizers
  • Record-breaking 99% weighted efficiency
  • Quick and easy inverter commissioning directly from a smartphone using SolarEdge SetApp
  • Fixed voltage inverter for longer strings
  • Integrated arc fault protection and rapid shutdown for NEC 2014-2023 per articles 690.11 and 690.12
  • UL1741 SA certified, for CPUC Rule 21 grid compliance
  • Small, lightweight, and easy to install both outdoors or indoors
  • Built-in module-level monitoring
  • Optional: Faster installations with built-in consumption metering (1% accuracy) and production revenue grade metering (0.5% accuracy, ANSI C12.20)

Technical Specifications

Continuous AC Power Output
11400 W
Max Operating Voltage
264 V
Min Operating Voltage
211 V
AC Voltages
208/240 VAC
AC Frequencies
60 Hz
Topology
Transformerless
Phase
1 Phase
Maximum DC Input Voltage
400 VDC
Maximum DC Input Current
30.5 A
Peak Efficiency
99.2 %
CEC Efficiency
99 %
Enclosure Ratings
NEMA 4X

General Information

Type
String Inverter
Approvals
UL
CSA
FCC
