Catalog #
SEG-405-BMD-HV
Mfr. Part #
SEG-405-BMD-HV
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
304
Watts STC
405 W
Cells
108
Technology
PERC
Open Circuit Voltage (Voc)
37.22
Short Circuit Current (Isc)
13.7
Max Power Voltage (Vmpp)
30.93
Max Power Current (Impp)
13.1
Max Current
25 A
Efficiency
20.74
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
30
Frame Color
Black
Connector
MC4
Output Cables
12 AWG PV Wire(UL)/1200 mm
Temp Coefficient (Pmpp)
-0.35
Temp Coefficient (Voc)
-0.27
Fire Classification (Type)
Type 1
General Information
Dimensions
1722 L x 1134 W x 30 H mm
Weight
47.4 Lbs.
Series
Yukon
Approvals
IEC61215:2016; IEC 61730:2016; IEC62804
IEC61701
IEC62716
IEC60068
IEC61215
Fire Type (UL61730):Type1
ISO14001:2015; ISO9001:2015; ISO45001:2018
UL1703; UL61730/ETL/CEC
