Catalog #
EVPV400H
Mfr. Part #
EVPV400H
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
381
Watts STC
400 W
Cells
132
Technology
Monocrystalline
Open Circuit Voltage (Voc)
48.8
Short Circuit Current (Isc)
10.25
Max Power Voltage (Vmpp)
42.1
Max Power Current (Impp)
9.51
Max Current
25 A
Efficiency
21.6
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
30
Frame Color
Black
Backsheet Material
Plastic film (PET)
Connector
Staubli MC4 PV-KBT4/KST4 (4 mm²)
Output Cables
12AWG(4mm²)
Temp Coefficient (Pmpp)
-0.26
Temp Coefficient (Voc)
-0.24
Fire Classification (Type)
Type 2
General Information
Dimensions
1821 L x 1016 W x 30 H mm
Weight
45 Lbs.
Series
EVERVOLT® H
Approvals
IEC61215-2:2016 [Hailstone 35mm]|Fire Type 2 (UL 61730)|Salt Mist [IEC 61701] |PID [IEC 62804]|Ammonia Resistance [IEC 62716]|Lead-free acc. to RoHS EU 863/2015 [IEC 62321]
