Catalog #
MNEDC100
Mfr. Part #
MNEDC100
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Description
MidNite Solar MNEDC100 100A 150VDC Panel Mount Breaker
Black 100 amp 150VDC Panel Mount.
10,000 AIC
MidNite’s breakers are rated to break the full rated load at the rated voltage repeatedly, with NO DAMAGE. Always use a properly sized breaker for disconnecting.
All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure.
- Listed for 240vac and 150vdc
- Breaker Torque Value: 30 In-Lbs (3.4NM)
- Environmental Rating - Type 1 (Indoor)
- Listed for US and Canada
Technical Specifications
Max Current
100 A
Mounting Type
Panel Mount
Actuator Type
Toggle
DC Voltage
150 VDC
Input Current
100 A
General Information
Weight
0.25 Lbs.
Type
Circuit Breakers
Material
Copper/Aluminum
Use With
Uses one small 3/4" breaker space
