Catalog #
MB-B120AYB-375
Mfr. Part #
MB-B120AYB-375
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:

Technical Specifications

Watts PTC
283
Watts STC
375 W
Cells
120
Technology
HJT
Open Circuit Voltage (Voc)
44.4
Short Circuit Current (Isc)
10.6
Max Power Voltage (Vmpp)
37.8
Max Power Current (Impp)
9.9
Max Current
20 A
Efficiency
20.4
Max System Voltage
1000 V
Frame Material
Anodized Aluminum
Frame Thickness (mm)
35
Frame Color
Black
Backsheet Material
Water Barrier - Black
Connector
1: MC4; 2: MC4-Evo2; 3: UKT Energy PV-CO02; 4: TE Connectivity PV4-S1
Output Cables
PV cable 4 mm2 / 12 AWG, 1.2 m / 47.2 in
Series Fuse Rating (Amps)
20
Temp Coefficient (Pmpp)
-0.259
Temp Coefficient (Voc)
-0.234
Fire Classification (Type)
Type 2

General Information

Dimensions
1767 L x 1041 W x 35 H mm
Weight
43.4 Lbs.
Series
Meyer Burger Black
Approvals
IEC 61215:2016
IEC 61730:2016
UL 61730-1
UL 61730-2
PID (IEC 62804)
Salt Mist (IEC 61701)
