Catalog #
HIS-S405YH(BK)
Mfr. Part #
HIS-S405YH(BK)
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:

Technical Specifications

Watts PTC
405
Watts STC
405 W
Cells
132
Technology
Monocrystalline
Open Circuit Voltage (Voc)
45.6
Short Circuit Current (Isc)
11.33
Max Power Voltage (Vmpp)
37.9
Max Power Current (Impp)
10.69
Max Current
20 A
Efficiency
20.3
Max System Voltage
1500 V
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
32
Frame Color
Black
Backsheet Material
Highly resistant and weatherproof film (Black meshed transparent)
Connector
MC4
Output Cables
4mm² / 12AWG / (+)1,200mm, (-)1,200mm
Series Fuse Rating (Amps)
20
Temp Coefficient (Pmpp)
-0.347
Temp Coefficient (Voc)
-0.268
Fire Classification (Type)
Type 1

General Information

Dimensions
1924 L x 1038 W x 32 H mm
Weight
46.52 Lbs.
Series
YH Dual Black Max
Approvals
IEC 61215: 2016 Hailstone 40mm by kiwa PVEL
ISO 9001: 2015 Quality management systems
ISO 14001: 2015 Environmental management systems
ISO 45001: 2018 Occupational health and safety management systems

Datasheets
